全阻值(Total value )…………………………………………..100 OHM~2M OHM
阻值公差(The resistance tolerance )……………………..±5%, ±10%, ±15%
直线性(Linear )………………………………………………...±1%, ±2%, ±3%
TCR………………………………… ……1200PPM以内(Less than 1200PPM)
SMT阻值衰减(SMT resistance decay )………………..5%以内(Less than 5%)
耐磨寿命(Wear life )…………………….20万次以上(More than 200000 Cycle)
FPC线宽线距(FPC line width line from )……..大于0.3mm (More than 0.3mm)
FPC折弯次数(FPC bending number )…………大于50次(More than 50 Cycle)
硬度(Hardness)………………….大于50次(More than 50 Cycle --JIS D 0202 )
附着性(Adhesion )…….……………………….无剥落(No peeling--JIS D 0202 )
